Name: Water Pump Compact Pressure Sensor 0.5-4.5V Output Anti-Freezing 0.5%FS Stability
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK80MA
Price: 21.00 USD
Availability: InStock

صفحه اصلی > محصولات > Compact Pressure Sensor >

Water Pump Compact Pressure Sensor 0.5-4.5V Output Anti-Freezing 0.5%FS Stability

oem pressure sensor

precision pressure sensor

Compact Pressure Sensor Anti freezing

محل منبع:

هفی، چین

نام تجاری:

WNK

گواهی:

CE, SGS, ISO9001

شماره مدل:

WNK80MA

تماس با ما

درخواست نقل قول

Water Pump Compact Pressure Sensor 0.5-4.5V Output Anti-Freezing 0.5%FS Stability

Product Details

فشار ورودی:

0-1.6MPa

ثبات:

+/-0.5%FS، +/-1.0% FS (برای گزینه)

عنصر حسگر:

سنسور خازنی سرامیکی

درجه حفاظت:

IP67، IP65

نوع:

سنج ، مطلق

ورودی ولتاژ:

5VDC، 12VDC، 24VDC، 9-30V dc

دمای کاری:

-20C - 70C

برجسته کردن:

oem pressure sensor

precision pressure sensor

Compact Pressure Sensor Anti freezing

Payment & Shipping Terms

مقدار حداقل تعداد سفارش

5 قطعه

قیمت

negotiable

جزئیات بسته بندی

بسته بندی با ارزش دریا یا بسته بندی هوا

زمان تحویل

7-10 روز کاری

شرایط پرداخت

T/T، Western Union، MoneyGram

قابلیت ارائه

5000 عدد در ماه

Explosion Proof Compact Pressure Sensor With 4~20mA And High Accuracy 0.2%FS

بهترین قیمت رو بدست بیار

Ceramic Capacitive 15MPa IP65 I2C Water Pressure Sensor

بهترین قیمت رو بدست بیار

WNK 0.5-4.5V 4 - 20ma Pressure Transmitter 150Psi IP65

بهترین قیمت رو بدست بیار

WNK 0.5-4.5V 4-20ma Smart Absolute Gauge Pressure Sensor For Water Air Oil

بهترین قیمت رو بدست بیار

تماس با ما

هم اکنون تماس بگیرید

Product Description

Water Pump Compact Pressure Sensor 0.5-4.5V Output Anti-freezing 0.5%FS Stability

Description

WNK80MA is a series of high performance compact pressure Transmitter, by using ASIC signal conditioning chip and dry ceramic capacitive pressure sensor. It has features of anti-corrosion, anti-wear, shock resistance and vibration resistance. Its anti-overload capacity is up to 100 times of the range, completely solved poor overload in small range of other sensors. With high output and wide range, WNK80MA is especially suitable for manufacturing of high-performance industrial control pressure transmitter and harsh environment pressure measurement.

Technical Data

Applicable media	Liquid, Gas
Pressure range	0-1.6Mpa , 0-20Mpa, Customized
Pressure measurment	Gauge Pressure
Output	0.5-4.5V/4-20mA
Accuracy(linearity,Hysteresis and Repeatability)	0.5%F.S.(Typical), 1.0%FS ( for option)
Power supply	24VDC/12VDC/5VDC
Compensation temperature	-20~70ºC
Ambient temperature	-40~125ºC
Working temperature	-40~125ºC
Temperature drift(zero)	±0.15% F.S. (-20~85ºC)
Temperature drift(full range)	±0.15% F.S. (-20~85ºC)
power(electrical) connect	Parkard, M12, DIN43650, Cable outlet, Other
Mechanical connection	G1/4, 1/4NPT, 1/8NPT, M12*1.5, customize
Housing material	304 stainless steel

Application:

For oil,fuel,diesel,gas,water or air pressure.Can be used in oil tank,gas tank,diesel tank etc.
