Name: Stainless Steel Oem Pressure Sensor Absolute Micro 4-20ma 0.5-4.5V I2C
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK80MA
Price: 21.00 USD
Availability: InStock

صفحه اصلی > محصولات > Compact Pressure Sensor >

Stainless Steel Oem Pressure Sensor Absolute Micro 4-20ma 0.5-4.5V I2C

electronic pressure sensor

oem pressure sensor

0.5-4.5V I2C Oem Pressure Sensor

محل منبع:

هفی، چین

نام تجاری:

WNK

گواهی:

CE, SGS, ISO9001

شماره مدل:

WNK80MA

تماس با ما

درخواست نقل قول

Stainless Steel Oem Pressure Sensor Absolute Micro 4-20ma 0.5-4.5V I2C

Product Details

منبع تغذیه:

5 ولت Dc 9-32 ولت

محدوده:

0-10MPa

دقت خطی:

0.25% FS، 0.5% Fs، 1.0% FS

بندر فشار:

G1/4، NPT1/8 دیگر

نوع سنسور:

سنسور خازنی سرامیکی

اتصال الکتریکی:

هیرشمن کوچک، کابل کابل

حفاظت از ورود:

IP67 IP65

برجسته کردن:

electronic pressure sensor

oem pressure sensor

0.5-4.5V I2C Oem Pressure Sensor

Payment & Shipping Terms

مقدار حداقل تعداد سفارش

5 قطعه

قیمت

negotiable

جزئیات بسته بندی

بسته بندی با ارزش دریا یا بسته بندی هوا

زمان تحویل

7-10 روز کاری

شرایط پرداخت

T/T، Western Union، MoneyGram

قابلیت ارائه

5000 عدد در ماه

Explosion Proof Compact Pressure Sensor With 4~20mA And High Accuracy 0.2%FS

بهترین قیمت رو بدست بیار

Ceramic Capacitive 15MPa IP65 I2C Water Pressure Sensor

بهترین قیمت رو بدست بیار

WNK 0.5-4.5V 4 - 20ma Pressure Transmitter 150Psi IP65

بهترین قیمت رو بدست بیار

WNK 0.5-4.5V 4-20ma Smart Absolute Gauge Pressure Sensor For Water Air Oil

بهترین قیمت رو بدست بیار

تماس با ما

هم اکنون تماس بگیرید

Product Description

Stainless Steel Absolute Micro Compact Pressure Sensor 4-20ma 0.5-4.5V, I2C

Stainless Steel Oem Pressure Sensor Absolute Micro 4-20ma 0.5-4.5V I2C 0

Description

This product is high integration, small size, high precision, good stability, fast response speed, low power consumption, good consistency, resistance to overload ability strong impact and interference. With the function of over-voltage and over-current protection and the full temperature linear temperature compensation of this product which widely used in engine pipe of vehicle and ship, central air conditioner and freezing device, water treatment engineering, building water supply, industrial process detection and control, hydraulic pneumatic control engineering and other fields.

Features :
1. Temperature range: -20 to 85℃
2. Wide operation temperature range -40~125℃
3. High performance ceramic capacitive pressure sensor
4. Various 4~20mA/0.5~4.5V/1~5V/ 0~5V/ SPI/ I²C outputs available
5. Small dimensions, dimension customizble
6. Optional packard, M12, Small Hirschman connectors
7. OEM, ODM, customization service available
8. Process connector: G1/4, M12*1.5, 1/4NPT, 7/16-20UNF female

Application:

For oil,fuel,diesel,gas,water or air pressure.Can be used in oil tank,gas tank,diesel tank etc.
