Stainless Steel 1MPa 4.5v HVAC Liquid Pressure Sensor

Stainless Steel 1MPa 4.5v HVAC Liquid Pressure Sensor

HVAC Liquid Pressure Sensor

4.5v Liquid Pressure Sensor

Stainless Steel Liquid Pressure Sensor

محل منبع:

چین

نام تجاری:

WNK

گواهی:

CE

شماره مدل:

WNK84mA

تماس با ما
درخواست نقل قول
Product Details
رسانه های اندازه گیری شده:
گاز مایع و بخار
سیگنال خروجی:
0.5-4.5v
دمای محیط:
-20-70c
اتصال الکتریکی:
Packard/Mini Din43650/Cable Outlet/M12*4P
دقت:
1% FS
محدوده فشار:
0-1000 کیلو پاسکال، 1 مگا پاسکال، 10 بار
منبع تغذیه:
5 ولت
اتصال فرآیند:
خروجی کابل G1/4
مواد:
فولاد ضد زنگ
برجسته کردن:

HVAC Liquid Pressure Sensor

,

4.5v Liquid Pressure Sensor

,

Stainless Steel Liquid Pressure Sensor

Payment & Shipping Terms
مقدار حداقل تعداد سفارش
1 قطعه
قیمت
negotiable
جزئیات بسته بندی
بسته بندی کارتن خنثی یا طبق نیاز شما.
زمان تحویل
5-8 روز کاری
شرایط پرداخت
D/P، T/T، Western Union، Paypal
قابلیت ارائه
5000 قطعه / ماه
Product Description

0.5-4.5v Output Pressure Sensor Liquid Pressure Sensor for HVAC



Product Description

Applicable Media Liquid Gas
Pressure Range 0-10Bar 0-1000Kpa
Cell Ceramic Capacitive Pressure Sensor
Pressure Measurement Gauge Pressure Sealing Pressure
Output  0.5-4.5v
Power Supply 5V
Accuracy 1%FS
Working Temperature -20-70C
Ambient Temperature -40-110C
Temperature Drift(zero) ±0.15% F.S. (-20~70ºC)
Temperature Drift(full range) ±0.15% F.S. (-20~70ºC)
Electrical Connection Cable outlet
Mechanical Connection 1/4 NPT
Housing Material Stainless Steel





Product Spec

Stainless Steel 1MPa 4.5v HVAC Liquid Pressure Sensor 0Stainless Steel 1MPa 4.5v HVAC Liquid Pressure Sensor 1
