Name: Profibus Rtd Smart Temperature Transmitter 4-20ma Output Aluminium Housing
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK6T
Price: 403.00 USD
Availability: InStock

صفحه اصلی > محصولات > Smart Temperature Transmitter >

Profibus Rtd Smart Temperature Transmitter 4-20ma Output Aluminium Housing

smart temperature sensor

industrial temperature sensor

محل منبع:

هفی، چین

نام تجاری:

WNK

گواهی:

ISO

شماره مدل:

WNK6T

تماس با ما

درخواست نقل قول

Profibus Rtd Smart Temperature Transmitter 4-20ma Output Aluminium Housing

Product Details

محدوده اندازه گیری:

0~1300ºC، (ترموکوپل K)

دامنه منبع تغذیه:

9~45V (9~24V، سابق)

سیگنال خروجی:

4~20mA/Hart/Profibus PA

مواد:

محفظه آلومینیومی

رانش بلند مدت:

<0.1/سال

ضد:

ExiaII CT4

رسانه ها:

مایع ، گاز و بخار

برجسته کردن:

smart temperature sensor

industrial temperature sensor

Payment & Shipping Terms

مقدار حداقل تعداد سفارش

1 مجموعه

قیمت

negotiable

جزئیات بسته بندی

بسته بندی کارتن صادراتی استاندارد

زمان تحویل

5-7 روز کاری

شرایط پرداخت

T/T، Western Union، MoneyGram

قابلیت ارائه

5000 عدد در ماه

44mm Diameter Hart RTD Liquid Gas Temperature Transmitter

بهترین قیمت رو بدست بیار

Wireless Smart Temperature Transmitter For Timer Button Alarm Wake

بهترین قیمت رو بدست بیار

CE Resolution 0.1C 18v 36V Temperature Humidity Sensor

بهترین قیمت رو بدست بیار

Steam 24V PT100 Head Mounted Temperature Transmitter

بهترین قیمت رو بدست بیار

تماس با ما

هم اکنون تماس بگیرید

Product Description

Profibus Rtd Smart Temperature Transmitter 4-20ma Output

Description

WNK PROFIBUS-PA field bus WNK6T temperature transmitter is approved by PROFIBUS Nutzerorganisation e.V. For temperature sensor we can provide the thermal resister, thermocouple etc usually used in industry, we can also provide special sensor, including high temperature type,high pressure type,health type,with special material or with coating etc sensor. Customized sensor is also acceptable.

Features

1. High precision, digital precision up to :±0.01ºC
2. To reduce the overall cost of installation,maintenance and running
3. Install easily, more flexiable

4. LCD display, Menu-guided operation.

5, Self-diagnostics function

Data Sheet

Measuring media	liquid, gas and steam
Measuring range	-270~800 ºC (PT100 thermal resistor)
	0~1300ºC, (Thermocouple K)
Input	Thermocouple, RTD, MV, Resistive sensor
Power supply range	9~45V (9~24V, Ex)
Output signal	4~20mA/Hart/Profibus PA
Digital Accuracy	±0.01ºC, PT100 input
Internal cold end compensation error	<0.25ºC±0.1%/10ºC
Temperature drift	±0.05%/10ºCfull scale range
	0.1% between-10°C to 60°C
Effect of power supply on range	<0.005%/V full-scale range
Long term drift	<0.1/year
